- Size: 1000
- Place of Origin: SHIJIAZHUANG
- Brand Name: WUXING
- Model Number: wx-101
- Weight: 200000.000 kg
specification
capacity:2million-20million
length :2400mm-3000mm
width:1200mm-1220mm
thickness:7mm-15mm
capacity
Annual output(ten thousand /m2) | Electricity (KW) | Boiler(KW) | Electricity consumption(A) | Coal consumption(KG/H) |
200 | 100 | 1200 | 120 | 256 |
300 | 125 | 1400 | 170 | 300 |
400 | 160 | 1800 | 210 | 450 |
500 | 200 | 2400 | 240 | 678 |
600 | 200 | 3000 | 270 | 800 |
800 | 250 | 4600 | 300 | 959 |
1000 | 250 | 4600 | 325 | 1088 |
1200 | 315 | 6000 | 360 | 1360 |
1500 | 315 | 7400 | 400 | 1622 |
2000 | 400 | 9400 | 500 | 2162 |
3000 | 500 | 1400 | 735 | 3187 |
detail information
Annual output | 2million-20million |
Fuel | oil gas coal etc |
Kind of gypsum board | common paper-faced gypsum board |
Waterproof paper-faced gypsum board | |
Fire resistant paper-faced gypsum board | |
Type | hot-air drying type production line |
Conductive oil with pipes type |
The parameters of plaster board plant
Annual capacity
2 to 2 0 million sq.m
Type
Hot air
Heat conduction oil
Degree of automation of plaster board machine
Full-automatic
Semi-automatic
Fuel
Natural gas
coal
diesel
heavy oil
light oil
Raw materials and the material balance calculation per sq.m
Gypsum powder:6kg
Modified starch:30g
Foaming agent:10g
Faced paper:380g
Water:4.2kg
White emulsion:5g
Power consumption:0.157kwh
Plaster board product specification
Thickness: 7mm to 15mm
Width: 1200mm, 1220mm
Length: 1800mm-3000mm
Type:Common/waterproof/fireproof/damp-proof
Quality of final products, being conformity with GB/T9775-1999 (Equal to European Standard).
